Aluminum LED Strip PCB Circuit Board
Beton factory is a professional aluminum Led Strip PCB Circuit Board LED PCB manufacturer in China. Through 18 years of aluminum PCB board designing and manufacturing experience, Beton are able to provide high quality and cost effective single layer, double layer and multi layer aluminum pcb boards to global customers.
Description
Product Detail
Aluminum Led Strip PCB Circuit Board is a metal-based copper clad board with good heat dissipation. Generally, a single panel consists of a three-layer structure, that is, a circuit layer, an insulating layer and a metal base layer. Commonly found in LED lighting products.
Product Name : Aluminum Led Strip PCB Circuit Board
Material Type: Aluminum
PCB Board Thickness: 0.2mm
PCB Board Layer: double-sided
PCB Soldermask Color:white
PCB Silkscreen Color: black
PCB Surface Finish: OSP
Test Method: flying-probe/test rig/test fixture
Production Needed Files: Gerber files&Bom list
MOQ: 1PCS
Minimum Line Space: 0.1mm
Minimum Line Width:0.1mm
Aluminum PCB Performance
1. Heat dissipation
Compared with ordinary FR4 PCB, aluminum PCB performs better in heat dissipation and can dissipate heat quickly. Comparing FR4 PCB and aluminum PCB, the equivalent thickness is 1.5mm as an example. The thermal resistance of FR4 PCB is 20°C/W to 22°C/W, while the thermal resistance of aluminum PCB is 1°C/W to 2°C/W. Therefore, aluminum can dissipate heat well.
2. Thermal expansion
Thermal expansion and contraction are common properties of substances, and different substances have different thermal expansion coefficients. Aluminum PCBs are now excellent at dissipating heat, so the durability and reliability of the entire device and electronics can significantly reduce thermal expansion and shrinkage issues of components on the board surface. This advantage of aluminum PCB is especially applicable to the thermal expansion and contraction problem of SMT (Surface Mount Technology).
3. Dimensional stability
Aluminum-based PCBs have significantly stable dimensions. When they were heated from 30°C to 140°C or 150°C, their dimensions changed by only 2.5% to 3.0%.
4. Other
a. Suitable for power device SMT.
b. Effective circuit design thermal expansion.
c. Helps reduce operating temperature, improve product power density and reliability, and extend product shelf life.
d. Reduce product size and hardware and assembly costs.
e. Replace the fragile ceramic matrix with better insulating properties and mechanical durability.
