Our Medical PCB Circuit Board Assembly, Medical Electronics PCB Assembly, Rigid-flexible Fr4 Gold Plating Pcb and technologies have become a model of the industry with low energy consumption and high precision. We have established and completed a complete quality management system to ensure that all products are processed with high precision in the controlled process, so that the products have traceable quality files. While expanding the product application market and realizing the high-end of the industry, we continuously increase the investment in environmental protection and actively seize the high point of sustainable development. Our enterprise management style is fair, just, open, scientific decision-making, timely improvement, and prohibitions.

Type: Metal Core PCB

Place of Origin:  Guangdong, China

Brand Name:  OEM/ODM

Base Material:  FR-4

Copper Thickness:  0.5oz-10oz

Board Thickness:  0.4-8mm

Min. Hole Size:  0.2MM

Min. Line Width:  2mil

Min. Line Spacing:  2mil

Surface Finishing:  HASL, Immersio Silver/Gold

Board Size:  OEM

Color:  Warm White, Green

Service:  One Stop Turnkey Service

PCB Standard:  IPC-A-610 D/IPC-III Standard

How to make a Double sided  Metal (Aluminum) core printed ciruit board?

1. Drill Holes on the bare Aluminum Board

(The holes are larger than your PTH Holes in

Your design)

2. Fill the holes by resin.

3. Laminate dielectric layer

Bettwen Aluminu bare board and two copper foil

4. Drill the holes as your design on the same place

that drilled on first step process

5. Plate through holes

6. Manufacturing trace layer etc….

Then Other process as FR4 PCB boards. It is important to choose the highly appropriate substrates for your electronic circuits.

There are different kinds of boards available,

but ceramic pcb get more fame among circuit board users because of its versatility.

Aluminium nitride ceramic PCB application

High power electronic semi-conductor module

Injection System

Anti-block Braking system

High-power LED Chip

Wafter Street light

Fuel Sendor Resistor Card

Electric power transmitter modules

Solar cell

Sensor

Telecome device

With better versatility,

It appears as a perfect alternative to existing printed circuit board boasting of increased

performance and minimal complex design.

It ensures that ceramic pcb work effectively on chip-on-board modules, high-power circuits,

and proximity sensors.

Our China Double Side LCD and LED PCB Manufacturer is well known in the industry for its perfect combination of innovative design and excellent performance. We hope that every employee should take up the professional responsibility of doing things with heart and conscientiousness, and be a person with a sense of responsibility and professionalism. According to the needs of every customer, we give customized & personalised services to help customers achieve their goals successfully.
